5/16" Lag Shield Anchors

ApplicationsThe anchor is made from Zamac Alloy. EnvironmentThe anchor is designed for use in a Wet environment. Hole Diameter/Bit DiameterThe anchor requires a 1/2 hole to be drilled in the base material (Concrete, Block, and Brick). Minimum EmbedmentThe minimum anchor embedment into the concrete is 1-3/4. Spacing between AnchorsEach anchor must be spaced a minimum distance of 5 from each other when measured center to center. Edge DistanceIt is very important not to install the anchor any closer than 2-1/2 from an unsupported edge of the concrete. ANCHOR IS MADE FROM RUST RESISTANT MATERIAL-Can be used in areas where moisture is present if the bolt used is rust resistant BOLT EXPANDS ANCHOR-No setting tool required; fast and easy LAG SCREWS MUST BE USED-Easy to find many lengths and diameters
